Emergency generator??

Discussion in 'Electronics' started by richierich33, Nov 7, 2023.

Page 3 of 3
  1. Capt J, Nov 23, 2023
    #41
    Capt J

    Capt J Senior Member

    Joined:
    Jul 11, 2005
    Messages:
    14,540
    Location:
    Fort Lauderdale
    When you had a bunch of halogens on 24v dc circuits, they would dim and brighten on their own as the battery charger goes through various modes of charging, or other dc loads kick on, that's why they used a transformer so the lights stayed on at an even brightness. A lot of yacht manufacturers do this.
  2. bobhorn, Nov 23, 2023
    #42
    bobhorn

    bobhorn Member

    Joined:
    Mar 3, 2014
    Messages:
    231
    Location:
    Kemah, TX
    How does a transformer work on 24VDC lights? Must have missed that class when working on my EE.
  3. Capt J, Nov 23, 2023
    #43
    Capt J

    Capt J Senior Member

    Joined:
    Jul 11, 2005
    Messages:
    14,540
    Location:
    Fort Lauderdale
    Woops meant 24v ac lights instead of dc lights.
  4. Capt Ralph, Nov 23, 2023
    #44
    Capt Ralph

    Capt Ralph Senior Member

    Joined:
    Sep 8, 2004
    Messages:
    13,497
    Location:
    Satsuma, FL
    But ACv lights don't need a battery charger? :rolleyes::rolleyes::D:D

    ACv halogen lamps will blink, even thru those lil hatteras transformers when some Air units cycle on or DCv halogens change while on charger or mains alternators.

    Our fix, Replace the ACv transformers with ACv to DCv power supplies and run DCv LED lamps.
    These power supplies or drivers keep the LEDs at a constant level and still use very little current.
  5. rtrafford, Nov 24, 2023
    #45
    rtrafford

    rtrafford Senior Member

    Joined:
    Jul 13, 2019
    Messages:
    1,756
    Location:
    Vero Beach
    12v LED have better dimming qualities than 24v LED. Also, best to still run the dc power through a transformer designed for the LED bulbs by the manufacturer. Third party dimmers , like those made by Blue Sea, don't provide quality dimming control. At low setting the darn things flicker. There's actually a science here that needs to be followed...
  6. Pascal, Nov 24, 2023
    #46
    Pascal

    Pascal Senior Member

    Joined:
    Feb 29, 2008
    Messages:
    8,570
    Location:
    Miami, FL
    The boat has combination of dimmers.the guest rooms had small dimmers modules called I-something that were not working with LEds We just removed them as nobody was using them anyway and rewired the boxes. The master and all other areas have an older Lutron system which works fine with LEDs.

    it s always a bit hit or miss.

    problem with an 24 VAC system is that you need compatible bulbs which are harder to find. When I replaced the antique halogen stern floodlights I had to use DC - AC converters for the Lumitec fixtures to work
