pneumatic pop-up electronics enclosure

Discussion in 'Technical Discussion' started by Danvilletim, Oct 20, 2013.

You need to be registered and signed in to view this content.
  1. Danvilletim, Oct 20, 2013
    #1
    Danvilletim

    Danvilletim Senior Member

    Joined:
    Oct 30, 2011
    Messages:
    794
    Location:
    isleton, ca
    I'm looking for where you can buy these pneumatic pop-up enclosures that are very popular on sportfish. Any downside to these?
  2. Capt J, Oct 20, 2013
    #2
    Capt J

    Capt J Senior Member

    Joined:
    Jul 11, 2005
    Messages:
    14,530
    Location:
    Fort Lauderdale
    Yeah, if they break you cannot use your electronics unless you have a way to get to the backside of the console and unbolt it, then you need a way to pin it in the upright position. You're better off using an electric ram like many manufacturers use for small windshields that open....I cannot think of the popular one that Cabo uses.
  3. wdrzal, Oct 20, 2013
    #3
    wdrzal

    wdrzal Senior Member

    Joined:
    Feb 6, 2006
    Messages:
    414
    Location:
    Allegheny Mountains of Western Pa
  4. Bill106, Oct 21, 2013
    #4
    Bill106

    Bill106 Senior Member

    Joined:
    Jan 9, 2010
    Messages:
    390
    Location:
    Beaufort NC
    With a little planning they can also be done using gas springs like you see on the rear hatches on SUV's (except stainless marine versions!). This set of pop up's uses 50# charge springs on the larger pop-up and 40# on the smaller one.

    Attached Files:

  5. Danvilletim, Oct 21, 2013
    #5
    Danvilletim

    Danvilletim Senior Member

    Joined:
    Oct 30, 2011
    Messages:
    794
    Location:
    isleton, ca
    Nice. Are the boxes custom made or available for sale?
  6. Bill106, Oct 21, 2013
    #6
    Bill106

    Bill106 Senior Member

    Joined:
    Jan 9, 2010
    Messages:
    390
    Location:
    Beaufort NC
    Thanks! Those were custom made for a 63 we built a few years ago. The lids are 2" Divinycell foam cored and the sides and instrument faces are made out of King Starboard. Once you figure out the geometry for using the gas springs it isn't very difficult to install them if you have existing boxes or ones with lifts now.
