Mariner 33' Fuel Gauge not working

Discussion in 'Carver Yacht' started by BaySailorBill, Jul 18, 2011.

You need to be registered and signed in to view this content.
  1. BaySailorBill, Jul 18, 2011
    #1
    BaySailorBill

    BaySailorBill New Member

    Joined:
    May 1, 2010
    Messages:
    3
    Location:
    Narragansett Bay, RI
    For the past two years I've been working on my 1981 Carver Mariner 3306. She's a great live aboard for weekends on the water and she cruises pretty good too. I've rebuilt a half dozen boats over the years and I do all my own work, so I'm pretty handy on all aspects of marine repair.

    There is one issue that has stumped me though, since the day I got the boat the fuel gauge has never worked. I've changed the float/sending unit in the tank and replaced the gauge, but no luck. The needle doesn't move at all. When I test the gauge the needle jumps to full as it should, but it will not read the sending unit. Could I have a wire break somewhere?? Any suggestions???

    Thanks

    Attached Files:

  2. Fireman431, Jul 18, 2011
    #2
    Fireman431

    Fireman431 Senior Member

    Joined:
    Jan 11, 2010
    Messages:
    195
    Location:
    East central Florida
    If you're grounding the (pink) fuel sending unit wire to the (black) gauge ground and the gauge pegs, then you have continuity to the gauge. Simple as that. You also need to have a 12v+ source of power going to the gauge for it to read, which it gets from the ignition switch's "ON" position. More than likely that's where you're problem lies. Check for 12v+ to the gauge with a test light.
